WisMesh WiFi MQTT Gateway V1

RAKwireless · Fixed node

Compare with other devices

Price: $69.97[2]

Specifications

SpecificationValue
Product statusDiscontinued (EOL) [1]
LoRa chipSX1262 [4]
ProcessorESP32 [3]
Radio power158 mW (22 dBm) [8]
Frequency bandsUnknown
GPSOptional (add-on) [5]
Display typeNone [2]
Display sizeNone
Display detailsNone [2]
InputNone [1]
BatteryUnknown
Dedicated solar inputBuilt in [5]
AntennaExternal [2]
Connector: RP-SMA [2]
IP ratingIP65 [2]
Dimensions100 × 75 × 38 mm [2]
WeightUnknown
Earlier WisMesh WiFi Gateway with RAK11200 and separate RAK13300 in the Unify enclosure
Image: Rokland

Firmware support

FirmwareSupportDetails
MeshtasticOfficial [6]
Details
Build target(s)
rak11200
Minimum version
Unknown

Confirm your exact device in the official flasher before choosing a build.

Meshtastic web flasher
MeshCoreUnsupported—
UMSHUnsupported [7]—

Where to buy

Vendor / configurationPriceBased inShips from
Rokland
Meshtastic · 8xx / 9xx MHz$69.97
Observed 2026-10-19
🇺🇸🇺🇸

Some of these links are affiliate links; we may earn a commission at no extra cost to you. It doesn't change what we list or the order. Details.

Notes

The earlier gateway uses a RAK11200 WiFi/BLE core and separate RAK13300 LoRa module on a RAK19007 base board.[2] RAK has replaced it with the integrated RAK3312-based V2 following the end of production of the ESP32-WROVER used by RAK11200.[1]

Rokland’s SKU 116119 listing does not identify the supplied regional band.[2]

Sources

  1. RAKwireless WisMesh WiFi MQTT Gateway current revision and hardware update
  2. Rokland WisMesh WiFi Gateway RAK11200 SKU 116119 listing
  3. RAKwireless RAK11200 WisBlock WiFi Module datasheet
  4. RAKwireless RAK13300 WisBlock LPWAN module datasheet
  5. RAKwireless RAK19007 base board datasheet
  6. Meshtastic official device hardware API
  7. UMSH hardware support list
  8. RAKwireless WisMesh Station radio module output table

Last updated 2026-10-20
