T-Deck Max
LILYGO · Handheld
Price: $109.87[2]
Specifications
| Specification | Value |
|---|---|
| Product status | Active [2] |
| LoRa chip | SX1262 [1] |
| Processor | ESP32-S3 [1] |
| Radio power | 158 mW (22 dBm) [5] |
| Frequency bands | 433 MHz, 868 MHz, 915 MHz, 920 MHz [1] |
| GPS | Built in [1] |
| Display type | E-paper [1] |
| Display size | 3.1 in [1] |
| Display details | 3.1-inch 320 × 240 front-lit e-paper touchscreen [1] |
| Input | Keyboard, Touchscreen [1] |
| Battery | 1400 mAh [3] |
| Dedicated solar input | No [1] |
| Antenna | Internal / External [1] Connector: IPEX [1] |
| IP rating | Unknown |
| Dimensions | 120 × 66 × 13.5 mm [1] |
| Weight | Unknown |
Firmware support
| Firmware | Support | Details |
|---|---|---|
| Meshtastic | Unsupported | — |
| MeshCore | Supported [4] | Details
Confirm your exact device in the official flasher before choosing a build. MeshCore web flasher |
| UMSH | Unsupported [6] | — |
Where to buy
| Vendor / configuration | Price | Based in | Ships from |
|---|---|---|---|
| LILYGO | |||
| MeshCore / LILYGO · 868 / 915 / 920 MHz | $109.87 Observed 2026-10-19 | 🇨🇳 | 🇨🇳🇺🇸🇨🇦🇪🇺 |
Notes
LILYGO’s repository lists a 1,400 mAh battery; its wiki lists 1,500 mAh. The comparison uses the lower published capacity.[3][1]
LoRa can switch between internal and external antenna paths; the cellular A7682E antenna is separate.[1]
Sources
- LILYGO T-Deck Max documentation
- LILYGO T-Deck Max current product variants
- LILYGO T-Deck Max repository and board details
- MeshCore official flasher catalog
- LILYGO T-Deck Max product page
- UMSH hardware support list
Last updated 2026-10-20
