Vision Master E290

Heltec Automation · Dev-board

Compare with other devices

Price: $21.90[4]

Specifications

SpecificationValue
Product statusActive [1]
LoRa chipSX1262 [2]
ProcessorESP32-S3 [2]
Radio power126 mW (21 dBm) [2]
Frequency bands433.175–434.665 MHz, 470–510 MHz, 863–870 MHz, 902–928 MHz [1]
GPSNot supported [6]
Display typeE-paper [2]
Display size2.9 in [2]
Display details2.90-inch black-and-white E-Ink, 296×128 [2]
InputButtons [1]
BatteryNo built-in battery [1]
Dedicated solar inputNo [3]
AntennaExternal [2]
Connector: IPEX 1.0 LoRa antenna interface [2]
IP ratingUnknown
Dimensions87.96 × 36.63 × 12 mm [1]
Weight35 g [1]
Vision Master E290 product photo
Image: Heltec Automation

Firmware support

FirmwareSupportDetails
MeshtasticOfficial [5]
Details
Build target(s)
heltec-vision-master-e290
Minimum version
2.4.0.46d7b82

Confirm your exact device in the official flasher before choosing a build.

Meshtastic web flasher
MeshCoreSupported [9]
Details
Build target(s)
Heltec_E290_repeater, Heltec_E290_room_server
Roles
  • Repeater: Heltec_E290_repeater
  • Room server: Heltec_E290_room_server
Minimum version
1.9.0

Confirm your exact device in the official flasher before choosing a build.

MeshCore web flasher
UMSHUnsupported [10]—

Where to buy

Vendor / configurationPriceBased inShips from
Heltec Automation
Meshtastic · 433 / 470–510 / 863–870 / 902–928 MHz$21.90
Observed 2026-10-19
Unknown🇨🇳🇪🇺🇺🇸
OpenELAB
Global site
868 MHz		€27.25
Observed 2026-10-19
Unknown🇪🇺🇺🇸🇨🇳
Global site
433 MHz		€27.25
Observed 2026-10-19
Unknown🇪🇺🇺🇸🇨🇳
US site
915 MHz		$33.39
Observed 2026-10-19
Unknown🇪🇺🇺🇸🇨🇳
Rokland
View listing$29.97
Observed 2026-10-19
🇺🇸🇺🇸

Some of these links are affiliate links; we may earn a commission at no extra cost to you. It doesn't change what we list or the order. Details.

Notes

LoRa is provided by the optional HT-RA62/SX1262 module; the manufacturer rates its 902–928 MHz device configuration at 21 ±1 dBm.

[1] [2]

Sources

  1. Heltec Vision Master E290 product and current variants
  2. Heltec Vision Master E290 datasheet Rev. 0.3.1
  3. Heltec Vision Master E290 schematic Rev. 0.3.1
  4. Heltec E290 902–928 MHz Meshtastic SKU current price and stock
  5. Meshtastic official hardware device directory
  6. Meshtastic Vision Master E290 device documentation
  7. Meshtastic Vision Master E290 firmware target
  8. MeshCore Heltec E290 board configuration
  9. MeshCore official flasher device catalog
  10. UMSH hardware support list
  11. Heltec Vision Master E290 hardware update log
  12. Rokland Heltec Vision Master E290 LoRa BLE WiFi + 2.9 inch E-Ink screen listing
  13. OpenELAB global store: HELTEC ESP32S3 SX1262 E-Paper LoRa Meshtastic LoRaWAN 2.9 inch 868Mhz (page identifies Vision Master E290 / HT-VME290)
  14. OpenELAB US store: HELTEC ESP32S3 SX1262 E-Paper LoRa Meshtastic LoRaWAN 2.9 inch 915Mhz (page identifies Vision Master E290 / HT-VME290)

Last updated 2026-10-20
